Simplifying NixOS Configurations with Reusable Modules

Managing multiple NixOS machines quickly becomes unwieldy when you copy-paste configurations between hosts. You end up with duplicated code, inconsistent settings, and the nightmare of keeping everything in sync. After running a fleet of 10+ NixOS machines ranging from ARM routers to x86 servers, I developed what I call the “Constellation Pattern” - a modular system that eliminates configuration duplication while maintaining the flexibility to customize each host.

Note: All code examples in this post are from my real production NixOS configuration, available at github.com/arsfeld/nixos.

The Problem with Traditional NixOS Multi-Host Management

Most NixOS configurations start simple. You have one machine, one configuration.nix, and life is good. But as you add more hosts, you face several challenges:

Configuration Drift: Each host accumulates unique tweaks, making it impossible to apply consistent updates across your fleet.

Copy-Paste Hell: You copy working configurations between machines, creating maintenance nightmares when you need to update common settings.

All-or-Nothing Modules: Standard NixOS modules are often too rigid - you can’t easily enable just the parts you need on different hosts.

Dependency Management: Services on one host might depend on services running on another host, but there’s no clean way to express these relationships.

Here’s what a typical problematic setup looks like:

# hosts/server1/configuration.nix
{ pkgs, ... }: {
  # 200 lines of common configuration
  services.tailscale.enable = true;
  services.openssh.enable = true;
  # ... lots of repeated configuration

  # Server-specific stuff mixed in
  services.postgresql.enable = true;
}

# hosts/server2/configuration.nix
{ pkgs, ... }: {
  # Same 200 lines copied and pasted
  services.tailscale.enable = true;
  services.openssh.enable = true;
  # ... same repeated configuration

  # Different server-specific stuff
  services.nginx.enable = true;
}

Enter the Constellation Pattern

The Constellation Pattern solves this by creating opt-in feature modules that can be selectively enabled on any host. Instead of copying configuration, you compose your hosts from a set of reusable, well-tested modules.

The pattern consists of:

1. Base Module (constellation.common): Common configuration that nearly every host needs
2. Feature Modules: Specialized modules for specific capabilities (media, backup, services, etc.)
3. Host Configurations: Minimal files that just enable the modules they need

Here’s how my hosts are now configured:

# hosts/storage/configuration.nix
{
  constellation.backup.enable = true;
  constellation.services.enable = true;
  constellation.media.enable = true;
  constellation.podman.enable = true;

  # Host-specific configuration
  networking.hostName = "storage";
  # ... minimal host-specific settings
}

# hosts/cloud/configuration.nix
{
  constellation.podman.enable = true;
  constellation.backup.enable = true;
  constellation.services.enable = true;
  constellation.media.enable = true;
  constellation.supabase.enable = true;

  # Host-specific configuration
  networking.hostName = "cloud";
  nixpkgs.hostPlatform = "aarch64-linux";
}

Clean, declarative, and immediately obvious what each host provides.

Anatomy of a Constellation Module

Let’s examine the constellation.common module to understand the pattern:

# modules/constellation/common.nix
# Source: https://github.com/arsfeld/nixos/blob/master/modules/constellation/common.nix
{
  inputs,
  config,
  pkgs,
  lib,
  ...
}:
with lib; {
  options.constellation.common = {
    enable = mkOption {
      type = types.bool;
      description = "Enable common configuration";
      default = true;  # This is key - enabled by default
    };
  };

  config = lib.mkIf config.constellation.common.enable {
    # Nix configuration that every host needs
    nix = {
      settings = {
        experimental-features = "nix-command flakes";
        auto-optimise-store = true;
        substituters = [
          "https://nix-community.cachix.org?priority=41"
          "https://fly-attic.fly.dev/system"
          # ... more caches
        ];
        trusted-public-keys = [
          "nix-community.cachix.org-1:mB9FSh9qf2dCimDSUo8Zy7bkq5CX+/rkCWyvRCYg3Fs="
          # ... corresponding keys
        ];
      };
    };

    # Essential services every host needs
    services.tailscale.enable = true;
    services.openssh.enable = true;
    services.avahi.enable = true;

    # Common packages
    environment.systemPackages = with pkgs; [
      git htop tmux wget
      # ... essential tools
    ];

    # Security and performance defaults
    networking.firewall.trustedInterfaces = ["tailscale0"];
    zramSwap.enable = true;
    nix.gc = {
      automatic = true;
      dates = "Sat *-*-* 03:15:00";
      options = "--delete-older-than 30d";
    };
  };
}

Key principles:

• Single Responsibility: Each module has a clear, focused purpose
• Sensible Defaults: The module works out of the box with minimal configuration
• Override Capability: Hosts can still override specific settings when needed
• Dependency Declaration: Modules can reference other constellation modules

Real-World Example: Mixing Containers and Native Services

The true power of the Constellation Pattern emerges when modules orchestrate both container-based and native NixOS services seamlessly. This hybrid approach lets you choose the best deployment method for each service while maintaining a unified gateway and service discovery system.

Why the Hybrid Approach?

My constellation.media module runs the *arr stack (Sonarr, Radarr, Prowlarr) as containers because:

• NixOS modules for these services weren’t updated frequently enough
• Container images provide consistent configuration across updates
• The *arr ecosystem expects certain behaviors that containers handle better

Meanwhile, services deeply integrated with NixOS (like PostgreSQL databases, Grafana, or Gitea) run as native services for better system integration.

The Media Constellation in Action

# modules/constellation/media.nix
# Container-based services with automatic deployment
{
  config = lib.mkIf cfg.enable {
    media.containers = let
      storageServices = {
        # The full *arr stack as containers
        prowlarr = { listenPort = 9696; };
        sonarr = {
          listenPort = 8989;
          mediaVolumes = true;  # Automatically mounts media directories
        };
        radarr = {
          listenPort = 7878;
          mediaVolumes = true;
        };

        # Media servers with hardware acceleration
        plex = {
          mediaVolumes = true;
          network = "host";
          devices = ["/dev/dri:/dev/dri"];  # Intel GPU passthrough
        };
      };
    in
      lib.mapAttrs (addHost "storage") storageServices;
  };
}

# modules/constellation/services.nix
# Native NixOS services registered for gateway routing
let
  services = {
    storage = {
      # Native services get simple port registration
      grafana = 3010;
      gitea = 3001;
      postgresql = 5432;
      # Container services just need their exposed port
      jellyfin = 8096;
      immich = 15777;
      sonarr = 8989;
      radarr = 7878;
    };
  };

Unified Gateway System

Both container and native services register with the same gateway system:

# All services - container or native - get automatic:
# - Reverse proxy configuration (https://service.domain.com)
# - Service discovery across hosts
# - Authentication rules
# - Health monitoring

media.gateway = {
  enable = true;
  services = generateServices services;  # Works for both types!
};

The beauty of this approach:

• Use containers when they make sense: For services with complex dependencies or frequent updates
• Use native when better: For NixOS-integrated services or those needing deep system access
• Same gateway for everything: Users don’t know or care how services are deployed
• Flexible migration: Start with native, move to containers (or vice versa) without changing the gateway configuration

This flexibility is where the constellation system truly shines - it doesn’t force you into one deployment model but lets you choose the best tool for each job while maintaining a cohesive system.

Benefits of the Constellation Pattern

After running this pattern for over a year across 10+ hosts, the benefits are substantial:

Consistency: Every host gets the same base configuration, eliminating configuration drift.

Maintainability: Updating all hosts is as simple as updating a single module and redeploying.

Composability: New hosts are trivial to create - just enable the modules you need.

Testing: You can test new configurations on a single host before rolling out to the fleet.

Documentation: The module structure serves as living documentation of your infrastructure capabilities.

Flexibility: Hosts can still override specific settings when needed, maintaining NixOS’s flexibility.

Comparison with Alternatives

vs. NixOps: More lightweight and doesn’t require a separate deployment tool. Works with any deployment method (deploy-rs, nixos-rebuild, etc.).

vs. Terraform/Ansible: Purely declarative with NixOS’s atomic rollback capabilities. No imperative state management.

vs. Kubernetes: Simpler for homelab scale. No YAML hell, built-in secret management, and works on bare metal.

vs. Docker Compose: Better hardware integration, atomic updates, and cross-host service discovery built-in.

How It All Ties Together: Automatic Module Loading with Haumea

The magic that makes the Constellation Pattern truly effortless is haumea, a library that automatically loads all files as NixOS modules. Instead of manually importing each module file, haumea discovers and loads them for you:

# flake.nix
# Source: https://github.com/arsfeld/nixos/blob/master/flake.nix
let
  modules = inputs.haumea.lib.load {
    src = ./modules;
    loader = inputs.haumea.lib.loaders.path;
  };
in
  getAllValues modules  # Flattens nested module structure

This means:

• Zero Import Boilerplate: Drop a new .nix file in modules/ and it’s automatically available
• Nested Organization: Create subdirectories like constellation/ for logical grouping
• Instant Recognition: New constellation modules are immediately available to all hosts
• Clean Flake: Your flake.nix stays minimal and focused

Combined with the constellation pattern, this creates a self-organizing module system where adding new capabilities is as simple as creating a file in the right directory.

Advanced Patterns: A Glimpse into the Future

The Constellation Pattern enables sophisticated infrastructure patterns that would be complex to implement otherwise. Multi-host service meshes, automatic service discovery, hardware-aware deployments, and declarative secret distribution all become straightforward.

In a future post, we’ll explore these advanced patterns in detail, showing how constellation modules can orchestrate complex multi-host deployments, handle cross-host dependencies, and create self-healing infrastructure - all while maintaining the simplicity of enabling a single option.

Conclusion

The Constellation Pattern has transformed how I manage my self-hosted infrastructure. What started as a mess of copy-pasted configurations is now a clean, maintainable system that scales from a single Raspberry Pi to a full server fleet. By combining opt-in modules with automatic loading via haumea, the pattern achieves both flexibility and simplicity - the holy grail of infrastructure management.
